Kód: Vybrat vše
===PCM DTC P0231-63===
Code: P0231 - Fuel pump secondary circuit Low
Additional Fault Symptom: Signal is Above Maximum Threshold
Module: Powertrain Control Module
Diagnostic Trouble Code details: Fuel pump secondary circuit Low, The FP is commanded ON, but the secondary circuit monitor (returned over CAN) reports the pump is OFF.
===END PCM DTC P0231-63===
===PCM DTC P0571-63===
Code: P0571 - Brake Switch A Circuit
Additional Fault Symptom: Signal is Above Maximum Threshold
Module: Powertrain Control Module
Diagnostic Trouble Code details: Brake Switch A Circuit, Noise on the CAN derived signal is greater than the calibrated limit., CAN message times out. Fault status reported over CAN. The number of BLS transitions with no BPP switch transitions exceeds the calibrated limit.
===END PCM DTC P0571-63===
===PCM DTC P2121-63===
Code: P2121 - Throttle/Pedal Position Sensor/Switch D Circuit Range/Performance
Additional Fault Symptom: Signal is Above Maximum Threshold
Module: Powertrain Control Module
Diagnostic Trouble Code details: Throttle/Pedal Position Sensor/Switch D Circuit Range/Performance. APPS1 fault., The CAN message from the cluster is missing. The PCM receives APPS1 signal over the CAN network.
===END PCM DTC P2121-63===
===OBDII DTC None===
===ABS DTC None===
===EPS DTC U0155-20===
Code: U0155 - Lost Communication With The Instrument Panel Cluster Control Module
Module: Electronic-Controlled Power Steering
===END EPS DTC U0155-20===
===IC DTC U1900-20===
Code: U1900 - CAN Communication Bus Fault - Receive Error
Module: Instrument Cluster
Diagnostic Trouble Code details: CAN Communication Bus Fault - Receive Error
===END IC DTC U1900-20===
===RCM DTC U0155-20===
Code: U0155 - Lost Communication With The Instrument Panel Cluster Control Module
Module: Restraint Control Module
===END RCM DTC U0155-20===
===ACM DTC None===
===GEM DTC None===
. Pomůžete mi schéma najít? Díky.
